Capacitor Start Two Speed Evaporative Cooler Electro Motors
$0.00
Product Specification
| Type | Frame size | Output Power | Output Power | Rated Voltage | Speed in rated load | Rated Current | Rated Torque | Power factor | Starting / Rated Current | Starting / Rated Torque | Break down / Rated Torque | Inertia moment | Poles |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CS 56-4/6 | 56 | 0.55/0.18 | 3/4 / 1/4 | 220 | 1425/950 | 5.5/2.9 | 3.75/1.87 | 0.795/0.665 | 4.25 | 1.45 | 1.56/1.83 | 0.02488 | 1 |
Description
Constituent parts
1- Front bracket2- Sliding bearing
3- Bearing cap
4- MTG ring
5- Flinger ring
6- Holed dust cap
7- Rear bracket
8- Marked dust cap
9- Special terminal (switch)
10- Screws for fastening terminal (switch)
11- Winded core
12- Frame
13- Rotor
14- Shaft
15- Governor
16- Sleeve
17- Rubber washer
18- Plastic washer
19- Grommet washer
20- Connector cable(Capacitor & Switch)
21- Assembly bolts
22- Assembly nuts
23- Base
24- Base fasteners
25- Plastic handel
26- Sponge
27- Run capacitor
28- Capacitor cover
29- Capacitor cover screw
30- Terminal cover
31- screws of capacitor cover
32- Ground screw
33- Washer of ground screw
34- Specifications plate
